Dormer roof junction detail - Build 170(2019)

Abbreviation
Dormer roof junction detail
Valid from
1/02/2019

Information provider
BRANZ Limited
Information type
BUILD article
Format
HTML, PDF, Hard copy

Description

A very tricky roof-to-wall junction detail occurs at the top and bottom junctions of a monopitch dormer roof. Here is one option that, if built correctly, will be weathertight and look good.

AS PART of the Build roof-to-wall junction detail series, we look at the flashing requirements for the top and bottom junctions of a monopitch dormer roof (Figure 1). Although detailing of the junctions is described separately, construction of each must occur concurrently.

Scope

The article includes:

  • Construction sequence for bottom corner
  • Construction sequence for top corner
  • Some specifics from E2/AS1



For assistance with locating previous versions, please contact the information provider.
